Meteor Screen 10.1" IPS HDMI-compatible Capacitive Touch Screen with RGB Animated light compatible with Raspberry Pi, Jetson Nano, Beaglebone
With RGB running light design, this 10.1-inch IPS high-definition touch display provides a resolution of 1280 x 800, supports Raspberry Pi, Windows, Linux, Ubuntu and other systems, and is also compatible with Raspberry Pi 3/3B+/4B, Jetson Nano, Beaglebone, Banana Pi and other mainstream development boards.
Description
This 10.1-inch IPS HD touch display provides resolution of 1280 x 800 and supports multiple systems including Raspberry Pi, Windows, Linux, Ubuntu, etc. and it is also compatible with Raspberry Pi 3/3B+/4B, Jetson Nano, Beaglebone, Banana Pi, and other mainstream development board. The biggest difference between it and other screens is the RGB water light design on its back, which not only has 19 lighting modes to choose from but also can adjust the brightness. With the exclusive bracket, you can easily create a cool atmosphere together with the lights. HDMI-compatible communication supports plug and play and can be used in multiple scenarios such as Raspberry Pi screen, computer expansion screen, party entertainment system, etc.
It supports 5-point touch and multi-touch gestures, such as click, press, zoom in/out, etc. fast response. With three buttons, you can adjust the screen backlight, RGB light switch, switch the light mode and adjust the brightness. Just use the included HDMI-compatible cable and USB cable to easily connect to the computer without additional operations.
IPS HD 1280*800
178°Full Viewing Angle, offering excellent image and video performance.
Capacitive 5-Point Touch
Smooth, Accurate and Fast Response.
Variety of RGB Animation Lights
19 kinds of RGB light modes, the dial can be switched freely, and supports three-level brightness adjustment, creating a cool atmosphere.
Support Multiple Systems, Plug and Play
Great Compatibility with various OS and devices.
Connect with Raspberry Pi
The back side is reserved for Raspberry Pi 3/3B+/4B fixed assembly screw post, easily connect with Raspberry Pi
Feature
- IPS HD 1280*800 resolution and 178°Full Viewing Angle present you with an excellent visual experience.
- RGB water lights on the back create a cool atmosphere, 19 kinds of customized LED Flow the mode can be switched freely.
- Support backlight control
- Capacitive 5-Point Touch, smooth, accurate and fast response
- Use HDMI-compatible communication, touch-free drive, plug and play, and easy to use.
- Support Windows, Linux, Ubuntu, Kodi, etc.
- Compatible with Raspberry Pi 3/3B+/4B, Jetson Nano, Beaglebone
Specification
|
Display Panel |
Screen Size |
10.1 inch |
|
Touch |
Capacitive 5-Point Touch |
|
|
Backlight Control |
Support |
|
|
Digital input |
HDMI-compatible |
|
|
Panel brightness |
300cd / m² |
|
|
Contrast |
700: 1 |
|
|
Resolution |
1280X800 |
|
|
Viewing angle |
178°Wide Viewing Angle |
|
|
Appearance Dimension |
239*157.5*12.6mm |
|
|
Active display touch area |
216.57*135.36mm |
|
|
Power Supply |
DC 5V-2A |
|
|
Compatibility |
compatible with Raspberry Pi 3/3B+/4B |
|
|
Power consumption |
5.29w（100% brightness without lighting LED string lights） |
|
|
Panel |
6H Toughened Panel |
|
|
Net weight |
540g |
|
|
RGB light string |
RGB Light Model |
3535 models, RGB full-color light |
|
Location |
Located on the back of the screen, U-shaped layout |
|
|
Quantity |
27 pcs lamp beads, the interval is about 22mm |
|
|
Brightness |
A total of three gears (with button adjustment) |
|
|
Power consumption |
7.6W (RGB 100% brightness, screen 100% brightness) |
|
|
Mode |
19 Modes |
|
Button |
Backlight |
Press it once to increase the brightness by 10%. After reaching 100%, press it again to return to 10%; press it for 3 seconds to turn off the backlight and press it again to restore the original brightness |
|
RGB ON/OFF |
Turn on the power to automatically start the light (the running light mode when the power was turned off the previous time), click to turn off the marquee function, and then press to turn on the marquee (run the previous mode) |
|
|
RGB Mode（dial） |
Toggle left: Last light mode Toggle right: Next light mode Middle press: marquee light brightness adjustment; (preset three gear adjustment, from dark to bright in turn, note: there is no light-off function) |
Noted: In the case of 5V 1A， RGB is not turned on, and the brightness can only be adjusted to 90%
RGB turns on 3-level brightness, and the brightness can only be adjusted to 30%
Package List
- 1x 10.1 inch monitor
- 1x HDMI-compatible Cable
- 1x Micro USB Cable(45cm)
- 1x Micro USB Cable（100cm）
- 1x M2.5 Screw Pack
- 1x Phillips screwdriver
- 2x Bracket
- 1x Micro HDMI-compatible Adapter
